(unit : mm)

Diameter
S₁
S₂
D
F
L
25 (1")
3.5
2
21
≥ 55
≤ 4000
32 (")
3.5, 4
2
28
≥ 68
40 (")
3.5
2
36
≥ 80
50 (2")
4
2
46
≥ 90
65 (")
4.5
2.5
60
≥ 105
80 (3")
4.5
2.5
75
≥ 125
100 (4")
4.5
3
94
≥ 150
125 (5")
4.5
3.5, 4
117
≥ 185
150 (6")
4.5
4
142
≥ 215
200 (8")
4.5
4, 4.5
191
≥ 280




순번
SIZE mm
외경 mm
두께 mm
무게 kg

공차

공차
4.2m/ea
1
12 X 3
12
± 0.50
3
± 0.30
0.82
2
14 X 3
14
± 0.50
3
± 0.30
1.00
3
15 X 5
16
± 0.50
5
± 0.50
1.52
4
15 X 6.5
15
± 0.50
6.5
± 0.50
1.68
5
184
18
± 0.50
4
± 0.40
1.70
6
18 X 3.25
18
± 0.50
3.25
± 0.40
1.45
7
18 X 3
18
± 0.50
3
± 0.30
1.36
8
22 X 3
22
± 0.50
3
± 0.30
1.73
9
23 X 3
23
± 0.50
3
± 0.30
1.82
10
24 X 4
24
± 0.50
4
± 0.40
2.43

11
25 X 2
25
± 0.50
2
± 0.30
1.40
12
26 X 3
26
± 0.50
3
± 0.30
2.09
13
30 X 3
30
± 0.50
3
± 0.30
2.46
14
40 X 4
40
± 0.50
4
± 0.40
4.37
15
42 X 3
42
± 0.50
3
± 0.30
3.55
16
42 X 4
42
± 0.50
4
± 0.40
4.61
17
43.5 X 3.5
43.5
± 0.50
3.5
± 0.40
4.25
18
45 X 3.25
45
± 0.50
3.25
± 0.40
4.12
19
51 X 2.5
51
± 0.50
2.5
± 0.30
3.68
20
51 X 3
51
± 0.50
3
± 0.30
4.37

21
51 X 4
51
± 0.50
4
± 0.50
5.7
22
50 X 9
50
± 0.50
9
± 0.50
11.19
23
58 X 4
58
± 0.60
4
± 0.50
6.55
24
64 X 2.5
64
± 0.60
2.5
± 0.30
4.66
25
65 X 4
65
± 0.60
4
± 0.50
7.4
26
65 X5
65
± 0.60
5
± 0.50
9.1
27
68 X 2.5
68
± 0.60
2.5
± 0.30
4.97
28
68 X 3
68
± 0.60
3
± 0.30
5.91
29
82 X 2.5
82
± 0.60
2.5
± 0.30
6.03
30
82 X 4
82
± 0.60
4
± 0.50
9.46

31
82 X 6
82
± 0.60
6
± 0.50
13.83
32
90 X 5
90
± 0.60
5
± 0.50
12.89
33
102 X 5
102
± 0.70
5
± 0.50
14.71
34
126 X 3.5
126
± 0.70
3.5
± 0.50
13.01
35
129 X 3.5
129
± 0.70
3.5
± 0.50
13.32
36
151 X 4
151
± 1.10
4
± 0.50
17.84
37
207 X 4.5
207
± 1.20
4.5
± 0.50
27.64
38
260 X 5
260
± 1.50
5
± 0.50
38.67


순번
SIZE mm
외경 mm
두께 mm
무게 kg

공차

공차
4.2m/ea
1
15.5 X 1.7
15.5
± 0.50
1.7
± 0.30
0.71
2
16 X 2
16
± 0.50
2
± 0.30
0.85
3
19.5 X 2
19.5
± 0.50
2
± 0.30
1.06
4
23 X 2.5
23.2
± 0.40
2.5
± 0.30
1.55
5
24 X 2
24
± 0.40
2
± 0.30
1.33
6
24 X 3
24
± 0.40
3
± 0.40
1.91
7
25 X 2
25
± 0.50
2
± 0.30
1.40
8
25 X 2.5
25
± 0.50
2.5
± 0.30
1.71
9
26 X 5.5
26
± 0.50
5.5
± 0.30
3.42
10
29 X 2
29
± 0.50
2
± 0.40
1.64

11
29 X 2.5
29
± 0.50
2.5
± 0.30
2.01
12
30 X 2
30
± 0.50
2
± 0.30
1.70
13
32 X 2
32
± 0.50
2
± 0.30
1.72
14
35 X 5
35
± 0.50
5
± 0.40
4.55
15
36 X 2.5
36
± 0.50
2.5
± 0.30
2.54
16
37 X 3.5
37
± 0.50
3.5
± 0.40
3.56
17
38.5 X 2
38.5
± 0.50
2
± 0.30
2.21
18
40 X 2
40
± 0.50
2
± 0.30
2.31
19
40 X 3
40
± 0.50
3
± 0.40
3.37
20
42 X 2
42
± 0.50
2
± 0.30
2.43

21
43 X 2
43
± 0.50
2
± 0.30
2.49
22
43 X 2.5
43
± 0.50
2.5
± 0.30
3.07
23
45 X 5
45
± 0.50
5
± 0.40
6.07
24
51 X 2
51
± 0.50
2
± 0.30
2.97
25
51 X 5
51
± 0.50
5
± 0.40
6.98
26
54.5 X 2
54.5
± 0.60
2
± 0.30
6.18
27
65 X 3
65
± 0.60
3
± 0.40
5.64
28
73.3 X 2.8
73.3
± 0.60
2.8
± 0.40
5.99
29
82 X 2
82
± 0.60
2
± 0.40
4.85
30
82 X 3
82
± 0.60
3
± 0.40
7.19

31
90 X 3
90
± 0.60
3
± 0.40
7.92
32
102 X 3
102
± 0.70
3
± 0.40
9.01
33
108 X 2.5
108
± 0.70
2.5
± 0.30
8.00
34
109 X 3
109
± 0.70
3
± 0.40
9.65
35
129 X 3
129
± 0.70
3.5
± 0.40
13.32
36
135 X 3.5
135
± 0.70
3.5
± 0.40
13.96
37
155 X 4
155
± 1.10
4
± 0.40
18.32
38
162 X 3
162
± 1.10
3
± 0.40
14.47
39
204 X 4
204
± 1.20
4
± 0.40
24.27
40
209 X 4
209
± 1.20
4
± 0.40
24.87
